This technology and equipment mainly use ultrasonic waves to achieve demulsification and colgulation so that the water particles in the emulsion will continue to move to the antinodes or nodes, accumulate and collide, forming droplets with larger diameters. Due to the difference in density, water droplets separate from the oil which effectively strengthens the purpose of crude oil dehydration.
Advantages of this technology:
(1) The use of ultrasound can reduce the amount of demulsifiers, or even completely replace the demulsifiers, which not only meets the requirements of the salt content of crude oil after desalination, but also saves the use of chemical agents, enabling enterprises to obtain good economic benefits.
(2) Ultrasonic intensified crude oil demulsification improves the qualified rate of electrical desalination and enables the device to process crude oil with severe emulsification and high salt content.
(3) Ultrasonic enhanced crude oil demulsification can significantly reduce electric desalination current, save electric desalination power consumption, stabilize electric desalination operation, reduce the number of trips due to ultra-high current, protect large-scale electric equipment such as electric desalination, and extend its service life. Ensure the quality of secondary processing raw materials.
(4) Ultrasonic enhanced crude oil demulsification has significantly improved the cutting water quality, and the later sewage treatment work has been greatly reduced.
(5) Compact structure, simple process, low energy consumption and convenient maintenance.
(6) Ultrasonic demulsification technology is a new environmentally friendly technology with no pollution, zero emission, low energy consumption and good effect.
Reference table of Electric desalination equipment reinforced with ultrosonic
Model | Volume of Tank (Cubic meter) | Rate Power (kw) | Processing Capacity per year |
(by 1000 cubic meters) | |||
DM-36 | 6.0 | No more than 3.5 | 1,000 |
8.0 | No more than 4.0 | 1,400 | |
10 | No more than 5.5 | 1,700 | |
15 | No more than 7.0 | 2,550 | |
20 | No more than 10 | 3,400 | |
30 | No more than 14 | 5,000 | |
40 | No more than 16 | 7,000 | |
50 | No more than 18 | 8,500 | |
60 | No more than 20 | 10,000 |
Application:
Demulsification of oil field crude oil
Demulsification of aging oil acidified oil
Deoiling of sewage,
Electric desalination of crude oil in petrochemical industry
Dehydration and decalcification of heavy oil.
